FNQ 13⁄32˝ x 1-1⁄2˝ 500Vac time-delay

Catalog symbol / color code:
• FNQ - Orange (500Vac maximum voltage)
Description:
Bussmann® series time-delay FNQ supplemental fuses.
For superior protection, upgrade to FNQ-R
Class CC fuses. See data sheet no. 1014.
Specifications:
Ratings
Fuse Amp Range                       Interrupting Rating at Rated Voltage                      Agency Information UL CSA
 1/10 to 30                                                              10kA                                                                   X X
Agency information
• UL® Listed, Std. 248-14, Guide JDYX, File E19180
• CSA® Certified: C22.2 No. 248.14, Class 1422-01, File 53787, HRC-MISC
• CE
• RoHS compliant
* * FNQ-1/8 not RoHS compliant.
